July 2014 News
New products
Easy to use, efficient and functional - that is how a well designed device should be. That is also the main goal for all SATEL products. We are constantly working on new devices as well as upgrading existing ones to guarantee highest quality that meets our clients' needs.
From the combination of SATEL's experience, knowledge and the will to provide installers and distributors with helpful devices, a set of new products has been created.
Professional expansion - SATEL's way
SATEL would like to introduce new devices, which are development versions of well known and acknowledged SATEL products. These novelties offer more options and are designed to help you get the most out of VERSA and INTEGRA based alarm systems - both at home and in company buildings.
Here are some things, that differ SATEL's new devices from their predecessors:
INT-O
Output expansion module
- replaces: CA-64 O-OC, CA-64 O-R
and CA-64 O-ROC - designed for use with INTEGRA, INTEGRA Plus and VERSA control panels
- expands the system with 8 additional outputs: OC type outputs, relay outputs or a combination of both these types
- connectable to RS-485 bus (firmware update through the bus)
INT-E
Zone expansion module
- replaces CA-64 E
- designed for use with INTEGRA, INTEGRA Plus and VERSA control panels
- support for 3EOL configuration (when working with INTEGRA Plus control panels)
- programming end-of-line resistor values
- connectable to RS-485 bus (firmware update through the bus)
INT-PP
Subpanel module
- replaces CA-64 PP
- designed for use with INTEGRA and INTEGRA Plus control panels
- support for 3EOL configuration (when working with INTEGRA Plus control panels)
- programming end-of-line resistor values
- the signals from zones are analyzed, which makes it possible to directly connect roller shutter detectors and vibration detectors
- connectable to RS-485 bus (firmware update through the bus)
INT-ADR
Addressable zone expansion module
- replaces CA-64 ADR
- designed for use with INTEGRA and INTEGRA Plus control panels
- connectable to RS-485 bus (firmware update through the bus)
ETHM-1 Plus
Ethernet communication module
- replaces ETHM-1
- designed for use with INTEGRA, INTEGRA Plus and VERSA control panels
- event notification capability using e-mail messages (only INTEGRA Plus)*
- UDP reporting
* available with v1.13 INTEGRA Firmware
But that's not all!
SATEL's offer is constantly growing to assure you a wide range of highest quality products, that correspond with your needs. As a response to those demands we provide more new devices:
TOPAZ Pet
Digital PIR motion detector, immune to pets up to 20 kg in weight
- new-generation digital detection algorithm to ensure good performance
- pet immunity up to 20 kg
- compensation of temperature
- built-in EOL resistors for easy installation
- compact and aesthetic enclosure that goes well with most interiors
USB-RS
USB-RS converter for programming SATEL devices
- build to replace cables for programming devices used so far: DB9F/RJ-KPL and DB9FC/RJ-KPL programming sets, and USB/RS232 converter
- makes it possible to connect to the computer and configure all SATEL devices provided with RS-232 or RS-232 (TTL) port
- suitable also for programming SATEL radio controllers (PIN3/RX adapter needed)
- 4 cables terminated with appropriate plugs
- USB type B socket for connecting the converter to the computer (1.8 m USB cable included)
* available soon
INT-SF
Partition keypad
- compatible with all alarm systems based on the control panels of INTEGRA and INTEGRA Plus families
- controls single partition in the system
- PANIC, FIRE and AUX alarms triggered from keypad
- access control functions
- relay for electromagnetic lock / electric strike control
- door status monitoring input
- white color backlight
- available in 2 color versions: light and dark (alike other keypads from this design line)
